Game Boy Advance / Color / Pocket Speaker

CUI
$7.34
| /

This premium speaker for the Game Boy Advance, Game Boy Color, and Game Boy Pocket delivers higher quality sound than most replacement speakers. Enjoy clearer, more robust audio on your favorite retro consoles.

For best results on the Game Boy Advance, pair this speaker with our in-house audio amplifier.

Features

  • Compatible with the GBA, GBC, and MGB
  • High-quality audio output
  • Significantly less noise and distortion compared to alternative replacement speakers
  • Pre-attached black and red wires to simplify installation
  • Adhesive around the speaker to improve mounting

Specs

  • Technology: Magnetic
  • Frequency Range: 440 Hz ~ 20 kHz
  • Frequency - Self Resonant: 550 Hz
  • Impedance: 8 Ohms
  • Efficiency - dBA: 80.00
  • Efficiency - Testing: 1W / 500 mm
  • Efficiency - Type: Sound Pressure Level (SPL)
  • Power - Rated: 1W
  • Power - Max: 1.5W
  • Port Location: Top
  • Shape: Round
  • Material - Cone: Polyester, Polyethylene Terephthalate (PET)
  • Material - Magnet: Nd-Fe-B
  • Termination: Wire Leads
  • Size / Dimensions: 0.906" Dia (23.00 mm)
  • Height - Seated (Max): 0.217" (5.50 mm)

Included

  • 1 x Premium speaker with pre-attached wires

Notes

Customer Reviews

Based on 38 reviews
82%
(31)
18%
(7)
0%
(0)
0%
(0)
0%
(0)
B
Blake
GBA speaker

Clean clear and crisp. GBA sound has always been a little fuzzy and this really helps cleaning it up.

A
Adam Alfaro
Good way to boost audio for GBC

Soldering all the wires was a bit of a hassle as well as knowing where to route them since there are no clear instructions but once you get past that, it works exactly as described, though the noise is a bit more prominent too.

D
David McAndrew
Great sound

Great sound! Easy to install!

C
Clayton LoCoco
A satisifed customer

Speaker is an amazing replacement for the original GBA speaker and works well with the audio board mod kit 10/10 product

M
Michael M.
Better than OEM, except...

This is a great replacement speaker, better than OEM, in sound and looks, a must if you are also doing a DAC upgrade or a clear shell. I ended up testing the original speaker and this one before replacement with a DAC. The original ends up sounding very tinny, crackles and distorts at louder volumes, where as the replacement handles the volume much better.

The only issue I had was with the wires and not the speaker. The wires are brittle in comparison to other types of wire I have used previously. With needing to route the speaker to the other side of the board, how tight the fit/bend is, and if you need to disassemble again for any reason you may run into the same issue that I did. 1 of the wires broke off right at the solder point on the DAC, once during initial install and once when I had to disassemble because I had forgotten the clear plastic power led piece. Not a big deal but the DAC I had said to insulate it with the provided shrink tube. I ended up cutting off the shrink tube, desoldering the piece of broken wire from the pad, resolder and then used some shrink tube I already had as a replacement.

If I ever order another one of these speakers, which is likely, I will be replacing the wires immediately as to alleviate any previous headaches.

TLDR; Great speaker, not so great wires.
